Mining Grade CMC is a high-performance rheology modifier engineered for extreme drilling environments, serving as a critical additive in water-based drilling fluid systems.
| Quantity: | |
|---|---|
Designed to withstand high temperatures, salinity, and pressure, this grade stabilizes drilling fluids to maintain wellbore integrity, lubricate drill bits, and suspend cuttings during oil, gas, and mineral exploration. Its unique molecular structure resists thermal degradation and salt-induced flocculation, ensuring consistent performance in challenging geological formations. Proven in deep-well applications up to 6000 meters, it reduces operational risks while improving drilling efficiency in both conventional and unconventional reservoirs.
Parameter | Specification |
Appearance | White to tan granular powder |
Viscosity (2% solution, 25°C) | 5000–15000 mPa·s |
Temperature Resistance | Up to 220°C |
Salt Tolerance | Stable in 15% NaCl solution |
Degree of Substitution (DS) | 0.7–0.9 |
pH Stability Range | 8.0–11.0 |
Moisture Content | ≤10% |
Extreme Temperature Stability: Maintains viscosity control up to 220°C, critical for deep-well drilling in geothermal and hydrocarbon reservoirs.
High Salt Tolerance: Resists flocculation in 15% NaCl environments, eliminating performance issues in salt-rich formations.
Wellbore Stabilization: Enhances shale inhibition and fluid loss control, reducing the risk of wellbore collapse in unstable formations.
Drilling Efficiency: Improves cuttings suspension and hydraulic pressure transmission, reducing torque and drag by 15–25%.
Oil & Gas Drilling: Stabilizes water-based muds in deep and ultra-deep wells, supporting record-breaking depths up to 6010 meters.
Mineral Exploration: Enhances drilling fluid performance in hard rock formations, improving penetration rates and sample recovery.
Geothermal Drilling: Withstands high-temperature conditions in geothermal energy exploration, maintaining fluid properties at extreme depths.
Q: How does Mining Grade CMC perform in high-density drilling fluids?
A: It maintains effective rheology control even in fluids weighted to 2.87 g/cm³ with barite, critical for balancing high-pressure formations.
Q: What dosage is recommended for different drilling conditions?
A: Typical addition rates range from 0.2–1.0% by weight of drilling fluid, with higher dosages (0.8–1.0%) recommended for high-temperature or high-salt environments.
