Carboxymethyl cellulose (CMC) serves important roles in the mining industry as a pellet binder and flotation inhibitor. It is a key component in the binder used for shaping mineral dust, and this binder is crucial for the production of pellets. CMC enhances the properties of wet, dry, and calcined pellets. Its effective binding and pellet-forming capabilities result in green pellets with superior anti-knock performance, high compressive strength, and excellent drop resistance. Furthermore, CMC can elevate the grade of the pellets. In the flotation process, CMC acts as an adjusting agent, serving as a silicate gangue inhibitor that helps control lead during the separation of copper and lead. It is also sometimes used as a dispersant for mineral slurries.
 |  |  |
| CMC Flotation Mining | CMC For Mining | Mining Grade CMC |
 |  |  |
| Mining Grade CMC | Pellet Production Binder | Mining Grade CMC |
Applications in Pellet Production
1. Excellent pellet formation and water control properties.
2. Converts pellets from hydrophilic to hydrophobic.
3. Delivers good dispersibility and high strength in wet pellets.
4. Ensures no distortion of pellets.
5. Provides strong mechanical strength in dry pellets.
6. Increases the compressive strength of pellets.
7. Exhibits high cracking temperatures, effectively controlling and releasing moisture within the pellets.
8. Achieves a homogeneous pellet size distribution.
9. Produces a smooth surface on the pellets.
10. Enhances metallurgical performance.
Applications in Flotation
1. Demonstrates good water solubility and strong inhibiting capabilities.
2. Improves the grade of finished ore and enhances specifications in ore selection.
3. Reduces the need for additional agents, thereby decreasing raw material consumption.
4. Primarily functions as a silicate gangue inhibitor, controlling lead in the separation of copper and lead, and occasionally works as a dispersant for slimes.
Model Indicators | OL6 | OH6 | OVH6 | OL9 | OH9 | OL6-A | OL6-G (granular) |
Viscosity, 2% (mPa·s) | 100-250 | 5000-7000 | ≥ 7000 | 100-250 | 5000-7000 | 200-400 | 300-500 |
Purity (%) | ≥ 95 | ≥ 98 | |||||
Degree of Substitution (D.S.) | 0.7-0.8 | ≥ 0.85 | 0.7-0.8 | ||||
pH | 6-10 | 6.0-8.5 | |||||
Moisture (%) | ≤10 | ≤12 | |||||
40 mesh sieve rate (%) | ≥99 | ≤ 40 | |||||
*We can customize according to the client's required specifications.
Mining and mineral processing require stable pellet formation, suitable wet and dry strength, controlled moisture release, and effective flotation selectivity. Mining Grade CMC supports these requirements through its binding, water control, dispersing, and inhibiting properties.
As a pellet binder, it helps improve pellet strength and size distribution. As a flotation inhibitor, it helps improve ore selection performance and reduce the need for additional agents. As a slurry dispersant, it can support more stable slurry behavior in selected mineral processing systems.
Mining Grade CMC provides effective binding and pellet-forming properties. It helps mineral dust form pellets with good wet strength, dry strength, and structural stability.
CMC supports water control in pellet production. It helps control and release moisture within the pellets and contributes to high cracking temperature performance.
Mining Grade CMC helps increase pellet compressive strength and mechanical strength. It supports green pellets with better anti-knock performance and drop resistance.
CMC helps maintain pellet shape without distortion. It also supports homogeneous pellet size distribution and smooth pellet surfaces.
By improving pellet formation, strength, moisture behavior, and size uniformity, Mining Grade CMC helps enhance metallurgical performance in pellet production.
Provides excellent pellet formation and water control properties
Helps convert pellets from hydrophilic to hydrophobic
Delivers good dispersibility and high strength in wet pellets
Helps prevent pellet distortion
Provides strong mechanical strength in dry pellets
Increases pellet compressive strength
Supports high cracking temperature performance
Helps control and release moisture within pellets
Achieves homogeneous pellet size distribution
Produces smooth pellet surfaces
Enhances metallurgical performance
Mining Grade CMC can function as a silicate gangue inhibitor in flotation. It helps improve flotation selectivity and supports ore separation performance.
In copper and lead separation, CMC helps control lead during the flotation process. This makes it useful as an adjusting agent in relevant mineral processing systems.
Mining Grade CMC helps improve the grade of finished ore and enhance specifications in ore selection.
By providing inhibition and adjustment functions, CMC can reduce the need for additional agents and help decrease raw material consumption.
Mining Grade CMC may also be used as a dispersant for mineral slurries, supporting slurry stability and processing control.
Provides good water solubility
Offers strong inhibiting capability
Helps improve finished ore grade
Enhances ore selection specifications
Reduces the need for additional agents
Helps decrease raw material consumption
Functions as a silicate gangue inhibitor
Helps control lead in copper-lead separation
Can be used as a dispersant for slimes or mineral slurries
Explore how Mining Grade CMC supports pellet binding, flotation inhibition, mineral slurry dispersion, and ore selection performance in mining applications.
Mining Grade CMC is available in multiple models for different mineral processing requirements.
Model Indicators | OL6 | OH6 | OVH6 | OL9 | OH9 | OL6-A | OL6-G (granular) |
Viscosity, 2% (mPa·s) | 100-250 | 5000-7000 | ≥ 7000 | 100-250 | 5000-7000 | 200-400 | 300-500 |
Purity (%) | ≥ 95 | ≥ 98 | |||||
Degree of Substitution (D.S.) | 0.7-0.8 | ≥ 0.85 | 0.7-0.8 | ||||
pH | 6-10 | 6.0-8.5 | |||||
Moisture (%) | ≤10 | ≤12 | |||||
40 mesh sieve rate (%) | ≥99 | ≤ 40 | |||||
Sentai provides customized CMC solutions according to customer requirements. For mining applications, different pelletizing and flotation systems may require different viscosity, DS, particle size, solubility, dispersion behavior, binding strength, inhibition performance, and slurry compatibility.
For pellet production, customization may focus on pellet formation, wet pellet strength, dry pellet mechanical strength, compressive strength, moisture control, cracking resistance, pellet size distribution, and surface smoothness. For flotation applications, customization may focus on water solubility, inhibition capability, ore grade improvement, reagent reduction, silicate gangue inhibition, copper-lead separation control, and mineral slurry dispersion.
Sentai can customize CMC specifications based on application needs, including DS, viscosity, particle size, and specialized performance requirements such as enhanced solubility or thermal stability. The available customization range includes DS from 0.4 to 1.5, viscosity from 20 to 10,000 mPa·s, and particle size from 10 to 300μm.
Through collaborative development, application testing, process optimization, technical support, and full-process quality control, Sentai helps customers select and customize Mining Grade CMC products according to mineral type, processing method, slurry conditions, and target production performance.
Mining Grade CMC is a carboxymethyl cellulose product used in the mining industry as a pellet binder, flotation inhibitor, and mineral slurry dispersant.
Mining Grade CMC is mainly used in pellet production and flotation. In pellet production, it helps improve pellet formation, strength, moisture control, size distribution, and surface quality. In flotation, it works as an inhibitor and adjusting agent for ore selection.
In pellet production, CMC acts as a binder for mineral dust shaping. It improves wet pellet strength, dry pellet mechanical strength, compressive strength, drop resistance, moisture control, and pellet size uniformity.
CMC helps green pellets achieve better anti-knock performance, high compressive strength, and excellent drop resistance.
Yes. Mining Grade CMC helps achieve homogeneous pellet size distribution and produces smooth pellet surfaces.
In flotation, Mining Grade CMC acts as an adjusting agent and silicate gangue inhibitor. It helps improve finished ore grade, enhance ore selection specifications, reduce additional reagent use, and control lead during copper-lead separation.
Yes. Mining Grade CMC is sometimes used as a dispersant for mineral slurries or slimes.
Available models include OL6, OH6, OVH6, OL9, OH9, OL6-A, and OL6-G Granular, with different viscosity, purity, DS, pH, moisture, and sieve rate indicators.
Yes. Sentai can customize Mining Grade CMC according to customer requirements, including DS, viscosity, particle size, solubility, dispersion performance, binding strength, and flotation inhibition requirements.
Yes. Sentai provides collaborative development, application testing, process optimization, technical support, and full-process quality control to help customers select and customize suitable CMC products for pellet production, flotation, and mineral slurry applications.
